Piper PA 23 Aztec/Apache panel CAD drawing

Looking for a new panel for your PA 32 Aztec / Apache? This Panel drawing is just what you need! Our PA23 panel drawing is designed to provide you with the an easy way to start your build when you upgrade an existing panel.

The PA 23 panel is equipped with all the essential 3 1/2 inch and 2 1/4 inch cut-outs you need for any panel configuration. The drawing can be easily changed with any CAD program to customize to your requirements.

Also included is a full size JPG or PDF file that can be printed out and used as a mounting or drilling template if you want to build your panel from sheet stock aluminum, carbon fibre, or other material.

If you want to modify any panel to suit your specific requirements, please contact us and we would be happy to work with you to create a custom panel.

We are sorry, but no refunds can be given on digital files.
We are however happy to work with you to modify purchased files to your requirements after you receive them.
Once the file has been downloaded or emailed it becomes the property of the purchaser. Each file is digitally marked to the original purchaser.

---
